| RATING | UPTO 630 Amp., UPTO 500V AC |
| CONSTRUCTION | IN AL. ALLOY LM6 |
| GAS GROUP | IIB AS PER IS/IEC 60079 -1:2014, Ex 'd' |
| ZONE | ZONE 1&2 |
| TEMP CLASS | T6 |
| DEG OF PROT | IP:66 AS PER IS/IEC 60529:2001 |
| CIMFR CERT NO | IN/CIMFR/TR20/3190 DTD. 09/11/2020. |
| PESO CERT NO | A/P/HQ/MH/104/6734 (P501680) DTD. 21/04/2021. |
| BIS CERT NO | ENDORSEMENT NO. 128 DTD. 19/01/2021 |
| EARTHING | 1NO. INTERNAL & 2NOS. EXTERNALS |
| PAINT | EPOXY POWDER COATED LIGHT GREY SHADE 631 OF IS:5 |
| TERMINALS | TO BE SPECIFY, ELMEX/CONNECTWELL MAKE |
| CABLE ENTRY | TO BE SPECIFY, WITHOUT CABLE GLANDS & WITHOUT PLUGS. |
| HARDWARE | S.S-304 (ONLY NUTS & BOLTS.) |
